XGPON Combo FT3630X is a FTTR all-optical home solution product independently developed by Shenzhen Kexint Technology Co., Ltd. It is a home terminal product that integrates Combo PON, VoIP, and high-speed WiFi 6. It can serve as a multi-service access and control center for households, providing users with high-speed internet access, voice call services, and WIFI. Besides, it solves the problems of low transmission rate, poor wireless coverage, and roaming cards in traditional home wireless networking, providing a true whole house WiFi gigabit broadband access experience for home users.
The FTTR home terminal series products mainly consist of two parts: the home all optical main gateway and the sub gateway.
FTTR Home Terminal All Optical Main Gateway Product Form:
FTTR all optical main gateway XGPON Combo FT3630X: XG-PON Combo uplink,
1 * GPON, 4 * GE electrical port,
1 * USB, Dual AX3000 WiFi6 (2x2MIMO),
1 * POTS voice port
Specification:
| ITEM | All-Optical Main Gateway-XGPON Combo FT3630X |
| Port | Uplink Port: XGPON Combo Interface
line Rate: XGPON downlink 9.95328Gbps, uplink 2.48832Gbps；GPON downlink2.48832Gbps,uplink 1.24416Gbps；
Downlink Port:1*GPON,1 * GPON, cascaded optical routing through splitters, can support up to 16 optical routing accesses.
4 * GE port, 1 * USB; AX3000 Dual band WiFi6(2x2MIMO); 1 * POTS voice port |
| Port Working Wavelength of Xgpon Combo | Complies with ITU-T G.987/G.988 standards
Central wavelength:XGPON downlink 1577nm ,uplink1270nm；
GPON downlink 1490nm,uplink 1310nm |
| Optical Interface Type | SC/UPC |
| Processor Capability | Dual Core 1G Hz |
| RAM | 4Gbit SDRAM |
| Storage | 2Gbit Nand Flash |
| EasyMesh | Support |
| VLAN | Support |
| Power Supply | Ac: Input 90 ~ 264V, 47 ~ 67Hz;
Adapter output DC: 12V/2A |
| Consumption | ≤15W |
| Weight | ≤0.7kg |
| Dimension(L*W*H) | 240*160*41(cm) |
| Environmental Parameters | Operating Temperature:-5°C～45°C
Storage Temperature:-40°C～70°C
Relative Humidity:10%～90%,no condensation |
| Button | Reset Button, WiFi Switch Button, WPS |
|
|
